1 - Introduction

Getting More Out of Feature Engineering and Tuning for Machine Learning

Welcome!

Wi-Fi network name

Posit Conf 2025

Wi-Fi password

conf2025

Venue information

  • There are gender neutral bathrooms located on floor LL2, next to Chicago A

  • A meditation/prayer room is located on floor LL2 in Chicago A

  • A lactation room is located on floor LL2 in Chicago B

Workshop policies

  • Please review the posit::conf code of conduct, which applies to all workshops: https://posit.co/code-of-conduct

  • CoC site has info on how to report a problem (in person, email, phone)

  • Please do not photograph people wearing red lanyards

Who are you?

  • You can use the magrittr %>% or base R |> pipe

  • You are familiar with functions from dplyr, tidyr, ggplot2

  • You have exposure to basic statistical concepts

  • You do need intermediate familiarity with modeling or ML

  • You have used some tidymodels packages

  • You have some experience with evaluating statistical models using resampling techniques

Who are tidymodels?

  • Simon Couch
  • Hannah Frick
  • Emil Hvitfeldt
  • Max Kuhn

+ our TA today, Edgar Ruiz!

Many thanks to Davis Vaughan, Julia Silge, David Robinson, Julie Jung, Alison Hill, and DesirΓ©e De Leon for their role in creating these materials!

Asking for help

πŸŸͺ β€œI’m stuck and need help!”

🟩 β€œI finished the exercise”

Discord

  • pos.it/conf-event-portal (login)
  • Click on β€œJoin Discord, the virtual networking platform!”
  • Browse Channels -> #workshop-feat-eng-tune

πŸ‘€

πŸ‘€

Tentative plan for this workshop

  • Model optimization by tuning
    • Grid search
    • Racing
  • Feature engineering with recipes
  • Postprocessing
  • Feature selection

Introduce yourself to your neighbors πŸ‘‹

Getting the materials


If you are using Posit Cloud:

Log in to Posit Cloud (free): Link on Discord


If you are working locally:

# local download
usethis::use_course("tidymodels/workshops", destdir = "some_path")

# or fork via
usethis::create_from_github("tidymodels/workshops", fork = TRUE)

Let’s install some packages

If you are using your own laptop instead of Posit Cloud:

# Install the packages for the workshop
pkgs <-
  c("almanac", "betacal", "bonsai", "brulee", "C50", "Cubist", "desirability2",
    "dimRed", "earth", "embed", "extrasteps", "finetune", "igraph",
    "important", "irlba", "kknn", "lightgbm", "lme4", "mirai", "parallelly",
    "plumber", "probably", "RANN", "rpart", "RSpectra", "rules",
    "splines2", "stacks", "text2vec", "textrecipes", "tidymodels",
    "uwot", "vetiver")

install.packages(pkgs)

Also, you should make sure that you have installed the newest version of a few packages. To check this, you can run:

rlang::check_installed("tidymodels", version = "1.4.1")
rlang::check_installed("embed", version = "1.2.0")

Let’s get started!

Load tidymodels

We’re here to learn more about how to use the more advanced bits of tidymodels for supervised learning. Let’s load the meta-package:

library(tidymodels)
#> ── Attaching packages ──────────────────────────── tidymodels 1.4.1 ──
#> βœ” broom        1.0.9     βœ” rsample      1.3.1
#> βœ” dials        1.4.2     βœ” tailor       0.1.0
#> βœ” dplyr        1.1.4     βœ” tidyr        1.3.1
#> βœ” infer        1.0.9     βœ” tune         2.0.0
#> βœ” modeldata    1.5.1     βœ” workflows    1.3.0
#> βœ” parsnip      1.3.3     βœ” workflowsets 1.1.1
#> βœ” purrr        1.1.0     βœ” yardstick    1.3.2
#> βœ” recipes      1.3.1
#> ── Conflicts ─────────────────────────────── tidymodels_conflicts() ──
#> βœ– purrr::discard() masks scales::discard()
#> βœ– dplyr::filter()  masks stats::filter()
#> βœ– dplyr::lag()     masks stats::lag()
#> βœ– recipes::step()  masks stats::step()

Resolve naming conflicts

You might want to run this function to avoid function name conflicts:


tidymodels_prefer()


To get more details, use the quiet = FALSE option.

Data sets

For illustration, we’ll use a few different data sets today:

  • class_data: a simulated set of data with a 1:10 class imbalance. Two classes, 30 predictors, and 2,000 data points.
  • leaf_data: a real data set to identify plant species from their leaves. Thirty-two levels, 53 predictors, and 1,907 data points.
  • hotel_data: a real data set for predicting the average cost per night. Numeric outcome, 27 predictors, and 15,402 data points.


Let’s get warmed up with the first data set.

Imbalanced data

These data can be loaded from the GitHub repo:


"https://raw.githubusercontent.com/tidymodels/" |>
  paste0("workshops/main/slides/class_data.RData") |>
  url() |>
  load()


The outcome column is class with levels "event" and "no_event". Predictors are "predictor_01" to "predictor_30".

Your turn

Let’s warm up by taking 8 minutes to explore the data.


We’ll ask you to tell us something about these data that might be interesting for modeling.

08:00

A quick review of tidymodels

Data splitting

One of our first tasks is to split our data into (at a minimum) a training set and a testing set. The rsample package has numerous functions for this, prefixed by initial_.

Let’s create a 3:1 split of the simulated data and use a stratified random sample (by class):

set.seed(429)
sim_split <- initial_split(class_data, prop = 0.75, strata = class)
sim_split
#> <Training/Testing/Total>
#> <1499/501/2000>

sim_train <- training(sim_split)
sim_test  <- testing(sim_split)

Data splitting

sim_train |>
  ggplot(aes(class)) +
  geom_bar()

sim_test |>
  ggplot(aes(class)) +
  geom_bar()

Resampling

We’ll want to get accurate estimates of model performance.

Let’s use a resampling method to make multiple versions of our data (using 10-fold cross-validation).


For large amounts of data, a validation set is also a good alternative.

Resampling

set.seed(523)
sim_rs <- vfold_cv(sim_train, v = 10, strata = class)
sim_rs
#> #  10-fold cross-validation using stratification
#> # A tibble: 10 Γ— 2
#>    splits             id
#>    <list>             <chr>
#>  1 <split [1348/151]> Fold01
#>  2 <split [1349/150]> Fold02
#>  3 <split [1349/150]> Fold03
#>  4 <split [1349/150]> Fold04
#>  5 <split [1349/150]> Fold05
#>  6 <split [1349/150]> Fold06
#>  7 <split [1349/150]> Fold07
#>  8 <split [1349/150]> Fold08
#>  9 <split [1350/149]> Fold09
#> 10 <split [1350/149]> Fold10

Resampled data sets

model_data_1 <- sim_rs |> get_rsplit(1) |> analysis()
model_data_1 |> count(class)
#> # A tibble: 2 Γ— 2
#>   class        n
#>   <fct>    <int>
#> 1 event      151
#> 2 no_event  1197

perf_data_1 <- sim_rs |> get_rsplit(1) |> assessment()
perf_data_1 |> count(class)
#> # A tibble: 2 Γ— 2
#>   class        n
#>   <fct>    <int>
#> 1 event       17
#> 2 no_event   134

Models via parsnip

Let’s fit a simple decision tree to the data:

# Specify what you want
tree_spec <- decision_tree(mode = "classification")

# Then train:
tree_fit <- tree_spec |> fit(class ~ ., data = model_data_1)
tree_fit
#> parsnip model object
#>
#> n= 1348
#>
#> node), split, n, loss, yval, (yprob)
#>       * denotes terminal node
#>
#>  1) root 1348 151 no_event (0.11201780 0.88798220)
#>    2) predictor_27< -2.268929 76  11 event (0.85526316 0.14473684) *
#>    3) predictor_27>=-2.268929 1272  86 no_event (0.06761006 0.93238994)
#>      6) predictor_29>=2.144976 89  25 event (0.71910112 0.28089888)
#>       12) predictor_29>=2.599392 45   3 event (0.93333333 0.06666667) *
#>       13) predictor_29< 2.599392 44  22 event (0.50000000 0.50000000)
#>         26) predictor_18>=0.2344964 32  11 event (0.65625000 0.34375000)
#>           52) predictor_03< -0.2257182 16   1 event (0.93750000 0.06250000) *
#>           53) predictor_03>=-0.2257182 16   6 no_event (0.37500000 0.62500000) *
#>         27) predictor_18< 0.2344964 12   1 no_event (0.08333333 0.91666667) *
#>      7) predictor_29< 2.144976 1183  22 no_event (0.01859679 0.98140321) *

Predicting…

predict(tree_fit, new_data = head(perf_data_1, 4))
#> # A tibble: 4 Γ— 1
#>   .pred_class
#>   <fct>
#> 1 event
#> 2 event
#> 3 event
#> 4 no_event

predict(tree_fit, new_data = head(perf_data_1, 4), type = "prob")
#> # A tibble: 4 Γ— 2
#>   .pred_event .pred_no_event
#>         <dbl>          <dbl>
#> 1      0.855          0.145
#> 2      0.933          0.0667
#> 3      0.855          0.145
#> 4      0.0833         0.917

Augmenting…

tree_pred <- augment(tree_fit, new_data = perf_data_1)
tree_pred |> slice(1:5)
#> # A tibble: 5 Γ— 34
#>   .pred_class .pred_event .pred_no_event class predictor_01 predictor_02
#>   <fct>             <dbl>          <dbl> <fct>        <dbl>        <dbl>
#> 1 event            0.855          0.145  event       -1.64      -1.74
#> 2 event            0.933          0.0667 event       -0.846      0.477
#> 3 event            0.855          0.145  event        0.551      0.00571
#> 4 no_event         0.0833         0.917  event       -1.46      -0.335
#> 5 event            0.855          0.145  event       -0.194     -0.276
#> # β„Ή 28 more variables: predictor_03 <dbl>, predictor_04 <dbl>,
#> #   predictor_05 <dbl>, predictor_06 <dbl>, predictor_07 <dbl>,
#> #   predictor_08 <dbl>, predictor_09 <dbl>, predictor_10 <dbl>,
#> #   predictor_11 <dbl>, predictor_12 <dbl>, predictor_13 <dbl>,
#> #   predictor_14 <dbl>, predictor_15 <dbl>, predictor_16 <dbl>,
#> #   predictor_17 <dbl>, predictor_18 <dbl>, predictor_19 <dbl>,
#> #   predictor_20 <dbl>, predictor_21 <dbl>, predictor_22 <dbl>, …

Performance metrics

There are many yardstick metrics* for class predictions and probability estimates.

Let’s make a collection of metrics and then evaluate our model.

cls_metrics <- metric_set(brier_class, roc_auc, sensitivity, specificity)
tree_pred |> cls_metrics(truth = class, estimate = .pred_class, .pred_event)
#> # A tibble: 4 Γ— 3
#>   .metric     .estimator .estimate
#>   <chr>       <chr>          <dbl>
#> 1 sensitivity binary        0.647
#> 2 specificity binary        0.985
#> 3 brier_class binary        0.0429
#> 4 roc_auc     binary        0.899

* … and metrics for regression and others.

Recipes and workflows

Recipes are preprocessors that perform sequential operations on the predictors.


For example, to center and scale our predictors:

rec <-
  recipe(class ~ ., data = sim_train) |>
  step_normalize(all_numeric_predictors())


A model, a recipe, and other objects can be added to a workflow to have a single object for the whole modeling sequence:

tree_wflow <- workflow(rec, tree_spec)

Your turn

Fit a different type of decision tree, this time:

  • Using the C5.0 engine
  • Change the minimum number of samples required for splitting to 10.


Did performance change much?


05:00

Our versions

R version 4.5.1 (2025-06-13), Quarto (1.7.32)

package version
almanac 1.0.0
betacal 0.1.0
bonsai 0.4.0
broom 1.0.9
brulee 0.5.0
C50 0.2.0
Cubist 0.5.0
CVST 0.2-3
desirability2 0.2.0
dials 1.4.2
dimRed 0.2.7
dplyr 1.1.4
DRR 0.0.4
earth 5.3.4
embed 1.2.0
package version
extrasteps 0.3.0
finetune 1.2.1
forested 0.2.0
Formula 1.2-5
ggplot2 3.5.2
igraph 2.1.4
important 0.2.0
irlba 2.3.5.1
kernlab 0.9-33
kknn 1.4.1
lattice 0.22-7
lightgbm 4.6.0
lme4 1.1-37
mirai 2.5.0
modeldata 1.5.1
package version
parallelly 1.45.1
parsnip 1.3.3
plotmo 3.6.4
plotrix 3.8-4
plumber 1.3.0
probably 1.1.1
purrr 1.1.0
RANN 2.6.2
recipes 1.3.1
rpart 4.1.24
rsample 1.3.1
RSpectra 0.16-2
rules 1.0.2
scales 1.4.0
splines2 0.5.4
package version
stacks 1.1.1
tailor 0.1.0
text2vec 0.6.4
textrecipes 1.1.0
tidymodels 1.4.1
tidyr 1.3.1
tune 2.0.0
uwot 0.2.3
vetiver 0.2.5
workflows 1.3.0
workflowsets 1.1.1
yardstick 1.3.2
